Hardware
Standard&Protocol
IEEE802.3, IEEE802.3u
Interfaces
1*10/100Mbps WAN port
3*10/100Mbps LAN ports
Antenna
4*6dBi external antennas
Button
1*WiFi/WPS button
Power
Input：100-240V—50/60Hz 0.4A
Output：DC 9V1A
Dimension
220mm*141.5mm*49mm(L*W*H)
LED Indicator
SYS*1,WAN*1, LAN*1,WiFi*1
Wireless
Wireless Standard
IEEE 802.11ac/a/n @5GHz
IEEE 802.11b/g/n @2.4GHz
Data Rate
5GHz: Up to 867Mbps
2.4GHz: Up to 300Mbps
Frequency
Simultaneous dual band 2.4
Transmission Power
CE:
<20dBm(2.4G)
<23dBm(5G)
FCC:
<30dBm
Basic Features
SSID Broadcast: Enable/Disable
Transmission Power: high, medium, low
Beamforming
MU-MIMO
Wireless Security
WPA-PSK/WPA2-PSK, WPA/WPA2
Wireless Security: Enable/Disable
WPS(WiFi Protected Set-up) fast encryption
Software
Internet Connection Type
PPPoE, Dynamic IP, Static IP
PPPoE(Russia), PPTP(Russia), L2TP(Russia)
Operating Mode
Wireless Router Mode
Universal Repeater Mode
WISP Mode
AP Mode
